JL AUDIO Marine Stereo Remotes MMR-20-BE Round Remote Controller For MediaMaster

MMR-20-BE Round Remote Controller for MediaMaster

Round, wired, non-display remote controller for use with MediaMaster®

The MMR-20-BE is a wired remote controller engineered to add auxiliary control functionality to MediaMaster® source units.

Built for marine and off-road applications, its weatherproof (IP67 rated) design places frequently used functions of your MediaMaster® source unit in a simple, intuitive design that’s easy-to-use. Its large, backlit controls and LED source indicators are easily identifiable, day or night, with brightness settings that can be adjusted using your MediaMaster® source unit.

A small footprint and simple, one-hole design means the MMR-20-BE can be installed in even the tightest of spaces. Depending on your system layout, you may add up to three MMR-20-BE remote controllers to a single MediaMaster® source unit. Each MMR-20 can be connected up to 75 ft. (22.8 m) away from its source unit.

MediaMaster® remote control capabilities include:

• Power On/Off
• Source Select
• Volume Up/Down
• Track Up/Down (USB & BT)
• Track Fast-Forward/Fast-Rewind (USB)
• Favorite Up/Down (Radio)
• Play/Pause (USB & BT)
• Mute/Unmute (Radio & Aux)

Note: Requires MMC Connection Cables (sold separately). Connection cables are available in several lengths to fit your specific application. Y-splitters are also available to connect up to three remotes to a MediaMaster® source unit.

Specifications:

Maximum Mounting Panel Thickness	1.5 in / 38 mm
Mounting Hole Diameter	2 in / 50 mm
Rear Depth (A)*	1.16 in / 29 mm
Width (W)	2.36 in / 60 mm
Height (H)	2.36 in / 60 mm
Depth (D)	0.59 in / 15 mm
